Catamaran

Landing Platform Dock

Upgrade on the Speed- and Loadsharing controls

REGULATEURS EUROPA did a midlife upgrade on the Speed- and Loadsharing controls on board a Landing Platform Dock of the Dutch Navy. The new XIOS controls have been installed in the existing cabinets to replace the obsolete Viking V25 governors.

Excellent speed control and load sharing is performed by the XIOS digital electronic governors. The load sharing is according the master-slave principle in which 1 engine is speed controller, the master. The slave governors share their individual load on the communication bus and are used as positioners by the master governor.

Digital Governor XIOS UC

Offshore Supply Ship

Replacement with Viking35

Matthew Hirst, Engineering Superintendent of the Boston Putford Offshore Safety Ltd states:

"The Putford Achiever was fitted with Viking22 Governor systems controlling the Port and Stb'd Main Engines Wartsila 6L26A. We were informed though REGULATEURS EUROPA that these Viking22 where to shortly become obsolete and that the replacement for these units was the Viking35.

After the initial set up the vessel was able to take a pilot and navigate out of dock and proceed down the river Humber with perfectly good control of the Main Engines. We are delighted that the system has operated correctly since".

Viking35

Seagoing Vessel

Seagoing Vessel Governor Replacement

The seagoing vessel ARM22 Klaas Adriana is driven by a Caterpillar 3606 DI-TA engine. This engine is controlled by the 1100 series hydraulic governor from REGULATEURS EUROPA. The governor replaces the previously installed Woodward 3161 governor, which gave rise to increased maintenance costs and dysfunctions.

The HEINZMANN stepper motor drive board differs from our competitor's equipment in that allows analogue or digital speed setting.

RE Hydraulic Governor

System Upgrades for Catamaran Fast Ferries

Three Incat-built catamaran fast ferries operating in Japan, Taiwan and Denmark have been successfully upgraded to use the latest Viking35 and MVC products from REGULATEURS EUROPA and HEINZMANN for control of their four 20V28/33D (RK280) main propulsion engines.

As the upgrade minimised changes to the physical system and its functionality, the crew could continue to operate and maintain the system with very little additional training. Additionally, most spare parts already held by the operators could continue to be used.

Viking35 Digital Speed Governor

Ruston RK270

Regulateurs Europa Ltd Delivers Viking22 Upgrade

Regulateurs Europa Ltd in Colchester UK continue to build and deliver system upgrades to their Viking series of digital engine control panels. Our customers value the continuity and high level of support available from the team of experienced applications, software, and commissioning engineers at their factory in Colchester, UK.

Below is just one of the many more recent Viking35 upgraded engine control panels to ship offering the owner the transition from Viking22 to Viking35.

Upgrades are available for all previous versions of the Viking range. Viking22 and Viking25 from the Colchester factory.

Viking35 Engine Control Panel
